Advanced-Grade Composite open triangle frame design makes shoulder carrying easy, while the V-shaped downtube efficiently sheds mud.
OverDrive 2 steerer combined with D-Fuse seatpost offer a lightweight, responsive and agile ride with precise steering.
Tubeless set-up, 1x drivetrain and up to 45mm tyre clearance makes this lightweight race machine daring enough to take on any cyclocross course.
| XS | 152 cm - 163 cm |
| S | 158 cm - 169 cm |
| M | 164 cm - 176 cm |
| XS | S | M | ||
|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 490 | 505 | 520 |
| B | Seat Tube Angle (degrees) | 74.0° | 74.0° | 73.5° |
| C | Top Tube Length (mm) (inch) | 510 | 520 | 535 |
| D | Head Tube Length (mm) (inch) | 108 | 123 | 138 |
| E | Head Tube Angle (degrees) | 70.3° | 71.0° | 71.5° |
| F | Fork Rake (mm) (inch) | 50 | 50 | 50 |
| G | Trail (mm) (inch) | 72.9 | 68.3 | 65.1 |
| H | Wheelbase (mm) (inch) | 1004 | 1009 | 1014 |
| I | Chain Stay Length (mm) (inch) | 430 | 430 | 430 |
| J | Bottom Bracket Drop (mm) (inch) | 60 | 60 | 60 |
| K | Stack (mm) (inch) | 514 | 531 | 547 |
| L | Reach (mm) (inch) | 363 | 368 | 373 |
| M | Stand Over Height (mm) (inch) | 773 | 788 | 802 |
| O | Stem Length (mm) (inch) | 70 | 80 | 90 |
| P | Crank Length (mm) (inch) | 165 | 170 | 170 |
| Q | Wheel Size | 700C | 700C | 700C |
| Sizes | XS, S, M |
| Colours | Dark Iridescent/Carbon/Chrome |
| Frame | Advanced-Grade Composite, 12mm thru-axle, disc |
| Fork | Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc |
| Shock | N/A |
| Handlebar | Giant Contact SL XS:38cm, S:38cm, M:40cm |
| Grips | Liv All Condition |
| Stem | Giant Contact SL XS:70mm, S:80mm, M:90mm |
| Seatpost | Giant D-Fuse SLR, composite, -5/+15mm offset |
| Saddle | Liv Alacra SL CS |
| Pedals | N/A |
| Shifters | Shimano GRX RX-810, 1x11 |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano GRX RX-810 |
| Brakes | Shimano GRX RX-810 hydraulic, Shimano SM-RT800 rotors [F]160mm, [R]140mm |
| Brake Levers | Shimano GRX RX-810 hydraulic |
| Cassette | Shimano Ultegra, 11-speed, 11x34 |
| Chain | KMC X11SL-1 |
| Crankset | Shimano GRX RX-810, 40t XS:170mm, S:170mm, M:170mm |
| Bottom Bracket | Shimano, press fit |
| Rims | Giant SLR-2 42 Carbon Disc WheelSystem |
| Hubs | Giant SLR-2 42 Carbon Disc WheelSystem |
| Spokes | Giant SLR-2 42 Carbon Disc WheelSystem |
| Tires | Maxxis All-Terrene, 700x33c, tubeless |
| Extras | Tubeless prepared, 45mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
