Advanced-Grade Composite frame and fork keeps your ride lightweight so you can sail up climbs and accelerate quickly on paved or gravel roads.
With clearance for 45c tyres and mounts for racks, accessories and three water bottle cages, this bike meets the demands of your next epic ride.
Internal cable routing and D-Fuse seatpost and handlebars keep this gravel bike clean and contoured for vibration-damping comfort and less maintenance.
| XS | 150 cm - 163 cm |
| S | 158 cm - 169 cm |
| M | 164 cm - 175 cm |
| L | 170 cm - 181 cm |
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 390 | 420 | 465 | 500 |
| B | Seat Tube Angle (degrees) | 75.0° | 75.0° | 74.5° | 74.5° |
| C | Top Tube Length (mm) (inch) | 515 | 525 | 535 | 550 |
| D | Head Tube Length (mm) (inch) | 95 | 125 | 155 | 180 |
| E | Head Tube Angle (degrees) | 70.5° | 70.5° | 71.0° | 71.0° |
| F | Fork Rake (mm) (inch) | 50 | 50 | 50 | 50 |
| G | Trail (mm) (inch) | 75.9 | 75.9 | 72.5 | 72.5 |
| H | Wheelbase (mm) (inch) | 1013 | 1020 | 1022 | 1039 |
| I | Chain Stay Length (mm) (inch) | 430 | 430 | 430 | 430 |
| J | Bottom Bracket Drop (mm) (inch) | 80 | 80 | 80 | 80 |
| K | Stack (mm) (inch) | 530 | 558 | 588 | 612 |
| L | Reach (mm) (inch) | 378 | 376 | 372 | 380 |
| L | ReachToHandlebar (mm) (inch) | 429 | 437 | 443 | 452 |
| M | Stand Over Height (mm) (inch) | 683 | 711 | 749 | 779 |
| O | Stem Length (mm) (inch) | 70 | 80 | 90 | 90 |
| P | Crank Length (mm) (inch) | 170 | 170 | 172.5 | 172.5 |
| Q | Wheel Size | 700c | 700c | 700c | 700c |
| Sizes | XS, S, M, L |
| Colours | Dynamic Bronze |
| Frame | Advanced-Grade Composite, 12x142mm thru-axle, disc |
| Fork | Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Giant Contact XR D-Fuse, 31.8 |
| Grips | Liv All Condition |
| Stem | Giant Contact XS:70mm, S:80mm, M:90mm, L:90mm |
| Seatpost | Giant Contact Switch, dropper |
| Saddle | Liv Approach |
| Pedals | N/A |
| Shifters | SRAM Rival eTap AXS, 1x12 |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM Rival eTap AXS XPLR |
| Brakes | SRAM Rival eTap AXS hydraulic, Giant MPH rotors [F]160mm, [R]160mm |
| Brake Levers | SRAM Rival eTap AXS hydraulic |
| Cassette | SRAM Rival, 12-speed, 10x44 |
| Chain | SRAM Rival D1 |
| Crankset | SRAM Rival D1 DUB, 40t XS:170mm, S:170mm, M:172.5mm, L:172.5mm |
| Bottom Bracket | SRAM DUB, press fit |
| Rims | Giant P-X2 Disc wheelset |
| Hubs | Giant P-X2 Disc wheelset |
| Spokes | Giant P-X2 Disc wheelset |
| Tires | Maxxis Rambler, 700x45c, tubeless |
| Extras | Giant 1x chain guide, tubeless prepared, 50mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
