A light and stiff Advanced-Grade Composite frame and wheelset maximizes your power and efficiency, especially noticeable on climbs.
29-inch wheels easily roll over small obstacles, while 100mm of Maestro suspension – tuned for women, by women – help absorb rougher trails.
An integrated dropper seatpost and clearance for up to 2.4-inch tyres means you can confidently ride moderately technical terrain.
| XS | 148 cm - 163 cm |
| S | 158 cm - 169 cm |
| M | 164 cm - 175 cm |
| L | 170 cm - 183 cm |
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 390 | 406 | 445 | 482 |
| B | Seat Tube Angle (degrees) | 74.0° | 74.0° | 74.0° | 74.0° |
| C | Top Tube Length (mm) (inch) | 565 | 580 | 595 | 610 |
| D | Head Tube Length (mm) (inch) | 90 | 95 | 100 | 110 |
| E | Head Tube Angle (degrees) | 68.5° | 68.5° | 68.5° | 68.5° |
| F | Fork Rake (mm) (inch) | 51 | 51 | 51 | 51 |
| G | Trail (mm) (inch) | 92.9 | 92.9 | 92.9 | 92.9 |
| H | Wheelbase (mm) (inch) | 1100 | 1115 | 1131 | 1147 |
| I | Chain Stay Length (mm) (inch) | 438 | 438 | 438 | 438 |
| J | Bottom Bracket Drop (mm) (inch) | 45 | 45 | 45 | 45 |
| K | Stack (mm) (inch) | 578 | 583 | 587 | 597 |
| L | Reach (mm) (inch) | 399 | 413 | 427 | 439 |
| M | Stand Over Height (mm) (inch) | 693 | 703 | 726 | 753 |
| O | Stem Length (mm) (inch) | 50 | 50 | 60 | 70 |
| P | Crank Length (mm) (inch) | 165 | 170 | 170 | 175 |
| Q | Wheel Size | 29" | 29" | 29" | 29" |
| Sizes | XS, S, M, L |
| Colours | Dark Blue |
| Frame | Advanced-Grade Composite front and rear triangles, 100mm Maestro Suspension |
| Fork | Fox 32 Float SC Performance Elite Live Valve, 100mm, FIT4 damper, Boost 15x110 Kabolt, tapered, 44mm offset, custom tuned for Liv |
| Shock | Fox Float Performance Elite Live Valve, 165/45, custom tuned for Liv |
| Handlebar | Giant Contact SLR XC, flat |
| Grips | Liv Supera, single lock ring |
| Stem | Giant Contact SL XC, 35mm XS:50mm, S:50mm, M:60mm, L:70mm |
| Seatpost | Giant Contact Switch dropper, remote |
| Saddle | Fi'zi:k Vento Argo R5 |
| Pedals | Platform |
| Shifters | Shimano Deore XT M8100, 1x12 |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano Deore XT M8100 |
| Brakes | Shimano SLX M7100, hydraulic, Shimano RT-64 rotors [F]180mm, [R]160mm |
| Brake Levers | Shimano SLX M7100 |
| Cassette | Shimano SLX M7100, 10x51 |
| Chain | KMC X-12 |
| Crankset | Shimano Deore XT M8100, 30t XS:165mm, S:170mm, M:170mm, L:175mm |
| Bottom Bracket | Shimano, press fit |
| Rims | Giant XCR-1 Carbon 29 WheelSystem |
| Hubs | Giant XCR-1 Carbon 29 WheelSystem |
| Spokes | Giant XCR-1 Carbon 29 WheelSystem |
| Tires | [F] Maxxis Recon Race, 29x2.25", foldable, TLR, EXO, tubeless [R] Maxxis Recon Race, 29x2.25", foldable, TLR, EXO, tubeless |
| Extras | Tubeless prepared, max tyre size 2.25", max chainring size 32t |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
