Advanced-grade composite open triangle frame design makes shoulder carrying easy, while the V-shaped down tube efficiently sheds mud.
OverDrive 2 steerer combined with a D-Fuse seatpost offer a lightweight, responsive and agile ride with precise steering.
Tubeless set-up, 1x drivetrain and up to 45mm tyre clearance makes this lightweight race machine daring enough to take on any cyclocross course.
| XS | 152 cm - 163 cm |
| S | 158 cm - 169 cm |
| M | 164 cm - 176 cm |
| XS | S | M | ||
|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 490 | 505 | 520 |
| B | Seat Tube Angle (degrees) | 74.0° | 74.0° | 73.5° |
| C | Top Tube Length (mm) (inch) | 510 | 520 | 535 |
| D | Head Tube Length (mm) (inch) | 108 | 123 | 138 |
| E | Head Tube Angle (degrees) | 70.3° | 71.0° | 71.5° |
| F | Fork Rake (mm) (inch) | 50 | 50 | 50 |
| G | Trail (mm) (inch) | 72.9 | 68.3 | 65.1 |
| H | Wheelbase (mm) (inch) | 1004 | 1009 | 1014 |
| I | Chain Stay Length (mm) (inch) | 430 | 430 | 430 |
| J | Bottom Bracket Drop (mm) (inch) | 60 | 60 | 60 |
| K | Stack (mm) (inch) | 514 | 531 | 547 |
| L | Reach (mm) (inch) | 363 | 368 | 373 |
| M | Stand Over Height (mm) (inch) | 773 | 788 | 802 |
| O | Stem Length (mm) (inch) | 70 | 80 | 90 |
| P | Crank Length (mm) (inch) | 165 | 170 | 170 |
| Q | Wheel Size | 700C | 700C | 700C |
| Sizes | XS, S, M |
| Colours | Messier/Carbon/Chrome |
| Frame | Advanced-Grade Composite, 12mm thru-axle, disc |
| Fork | Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc |
| Shock | N/A |
| Handlebar | Giant Contact SL |
| Grips | Liv All Condition |
| Stem | Giant Contact SL |
| Seatpost | Giant D-Fuse SLR, composite, -5/+15mm offset |
| Saddle | Liv Approach SL |
| Pedals | N/A |
| Shifters | SRAM Rival eTap AXS, 1x12 |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM Rival eTap AXS |
| Brakes | SRAM Rival eTap AXS hydraulic, SRAM PaceLine rotors [F]160mm, [R]140mm |
| Brake Levers | SRAM Rival eTap AXS hydraulic |
| Cassette | SRAM Rival, 12-speed, 10x36 |
| Chain | SRAM Rival D1 |
| Crankset | SRAM Rival D1 DUB, 38t |
| Bottom Bracket | SRAM DUB, press fit |
| Rims | Giant CXR 2 Carbon Disc WheelSystem |
| Hubs | [F] Giant alloy, CenterLock, 12mm thru-axle, [R] Giant alloy, 3-pawl driver, CenterLock, 12mm thru-axle |
| Spokes | Sapim Sprint |
| Tires | Maxxis All-Terrene, 700x33c, tubeless |
| Extras | Giant 1x chainguide, 45mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
