The SyncDrive Move rear motor delivers natural-feeling pedal assistance so young riders can climb hills with less effort and have more fun.
Lightweight aluminium frame with kid-friendly geometry and 80mm of front suspension travel helps young riders hit the trail with confidence and control.
RideControl Dash Integrated control unit with colour display makes it easy to change support modes and view ride data.
| One Size | 144 cm - 164 cm |
| One Size | ||
|---|---|---|
| A | Seat Tube Length (mm) (inch) | 320 |
| B | Seat Tube Angle (degrees) | 73.0° |
| C | Top Tube Length (mm) (inch) | 530 |
| D | Head Tube Length (mm) (inch) | 120 |
| E | Head Tube Angle (degrees) | 67.0° |
| F | Fork Rake (mm) (inch) | 40 |
| G | Trail (mm) (inch) | 101 |
| H | Wheelbase (mm) (inch) | 1053 |
| I | Chain Stay Length (mm) (inch) | 425 |
| J | Bottom Bracket Drop (mm) (inch) | 28 |
| K | Stack (mm) (inch) | 548 |
| L | Reach (mm) (inch) | 365 |
| M | Stand Over Height (mm) (inch) | 691 |
| O | Stem Length (mm) (inch) | 50 |
| P | Crank Length (mm) (inch) | 160 |
| Q | Wheel Size | 26" |
| Motor | Giant SyncDrive Move, Rear Hub, 30Nm |
| Controller | Giant RideControl Dash, Smart Assist automatic mode, 3 support levels, USB-C (10W) |
| Display | RideControl Dash, full colour lcd screen |
| Battery | EnergyPak 240Wh |
| Charger | Giant EnergyPak 4A fast charger, 60% charge in 1:20h |
| Maximum speed | 22 km/h |
| Connectivity | Giant RideControl App enabled ANT+ wireless display signal with e-bike profile |
| Sizes | 26" |
| Colours | Deep Lake |
| Frame | ALUXX-Grade aluminium, integrated KSA18 kickstand mount |
| Fork | SR Suntour XCM HLO 26", 80mm travel |
| Shock | n/a |
| Handlebar | Giant Connect XC Riser, 31.8mm |
| Grips | Giant Junior |
| Stem | Giant Connect, 50mm |
| Seatpost | Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium |
| Saddle | Giant Sport |
| Pedals | Platform |
| Shifters | Shimano Altus |
| Rear Derailleur | Shimano Alivio, 9-speed |
| Brakes | Tektro HD-M282, hydraulic disc, 160mm |
| Brake Levers | Tektro HD-M282 |
| Cassette | Shimano CS-HG200, 11-36T, 9-speed |
| Chain | KMC e.9 Sport |
| Crankset | Forged Alloy minimal Q-factor, 36T |
| Rims | Giant GX03V 26" Aluminium |
| Hubs | Giant eTracker Sport, 9mm QR[F] SyncDrive Move 142mm [R] |
| Spokes | Stainless steel |
| Tires | Maxxis Ikon 26x2.20" |
| Extras | KSA18 direct mount kickstand |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
