Advanced-grade composite frameset is 17.5 percent lighter than the previous generation while retaining its best-in-class torsional/pedalling stiffness.
Integrated disc brake technology with flat mounts and thru-axle hubs, combined with tubeless ready Giant WheelSystem, delivers added control in variable conditions and all types of weather.
D-Fuse composite seatpost helps absorb bumps and vibrations, and you also have the option to switch to a standard 30.9mm round or dropper post depending on your riding style and terrain.
| S | 166 cm - 174 cm |
| M | 172 cm - 180 cm |
| ML | 178 cm - 186 cm |
| L | 184 cm - 192 cm |
| XL | 190 cm - 198 cm |
| S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 505 | 525 | 545 | 555 | 565 |
| B | Seat Tube Angle (degrees) | 73.5° | 73.0° | 73.0° | 73.0° | 73.0° |
| C | Top Tube Length (mm) (inch) | 530 | 545 | 560 | 575 | 590 |
| D | Head Tube Length (mm) (inch) | 133 | 148 | 163 | 178 | 193 |
| E | Head Tube Angle (degrees) | 71.0° | 71.5° | 72.0° | 72.5° | 72.5° |
| F | Fork Rake (mm) (inch) | 50 | 50 | 50 | 50 | 50 |
| G | Trail (mm) (inch) | 68.3 | 65.1 | 61.8 | 58.6 | 58.6 |
| H | Wheelbase (mm) (inch) | 1014 | 1020 | 1030 | 1040 | 1055 |
| I | Chain Stay Length (mm) (inch) | 430 | 430 | 430 | 430 | 430 |
| J | Bottom Bracket Drop (mm) (inch) | 60 | 60 | 60 | 60 | 60 |
| K | Stack (mm) (inch) | 540 | 556 | 572 | 589 | 603 |
| L | Reach (mm) (inch) | 370 | 375 | 385 | 395 | 406 |
| M | Stand Over Height (mm) (inch) | 788 | 807 | 826 | 832 | 845 |
| O | Stem Length (mm) (inch) | 80 | 90 | 100 | 100 | 110 |
| P | Crank Length (mm) (inch) | 170 | 172.5 | 172.5 | 175 | 175 |
| Q | Wheel Size | 700C | 700C | 700C | 700C | 700C |
| Sizes | S, M, M/L, L, XL |
| Colours | Black Diamond/Airglow |
| Frame | Advanced-Grade Composite, 12mm thru-axle, disc |
| Fork | Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc |
| Shock | N/A |
| Handlebar | Giant Contact SLR |
| Grips | Stratus Lite 3.0 |
| Stem | Giant Contact SL |
| Seatpost | Giant D-Fuse SLR, composite, -5/+15mm offset |
| Saddle | Giant Approach SL |
| Pedals | N/A |
| Shifters | SRAM Force eTap AXS, 1x12 |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM Force eTap AXS |
| Brakes | SRAM Force eTap AXS hydraulic, SRAM CenterLine rotors [F]160mm, [R]140mm |
| Brake Levers | SRAM Force eTap AXS hydraulic |
| Cassette | SRAM Force, 12-speed, 10x36 |
| Chain | SRAM Force D1 |
| Crankset | SRAM Force D1 DUB, 40t |
| Bottom Bracket | SRAM DUB, press fit |
| Rims | Giant CXR 1 Carbon Disc WheelSystem |
| Hubs | [F] Giant AR alloy, CenterLock, 12mm thru-axle, [R] Giant AR alloy, DT350 36t ratchet system, CenterLock, 12mm thru-axle |
| Spokes | Sapim CX-Ray |
| Tires | Maxxis All-Terrene, 700x33c, tubeless |
| Extras | Giant 1x chainguide, tubeless prepared, 45mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
