The new SyncDrive motor has Smart Assist mode, which determines the support you need and automatically adjusts power output.
The Ride Dash Evo with on-board navigation is cleanly integrated into the stem to help riders find their way. Cables and wires for all cockpit controls, including the brakes, dropper seatpost lever, shifters, RideControl Ergo 2 and RideDash EVO, are internally routed and tucked into the frame for a tidy aesthetic.
The frame’s low-step-through design makes it easy to mount and dismount, and delivers a confident, comfortable ride. Purpose-built features including an integrated trailer mount and a rear carrier rack with a MIK HD interface makes it quick and easy to customise carrying capacity and add other accessories such as bags or a child seat with a secure click mechanism.
| S | 162 cm - 172 cm |
| M | 169 cm - 179 cm |
| L | 176 cm - 186 cm |
| XL | 183 cm - 193 cm |
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 340 | 410 | 480 | 550 |
| B | Seat Tube Angle (degrees) | 74.0° | 73.0° | 72.0° | 72.0° |
| C | Top Tube Length (mm) (inch) | 570 | 590 | 610 | 630 |
| D | Head Tube Length (mm) (inch) | 130 | 130 | 170 | 170 |
| E | Head Tube Angle (degrees) | 69.5° | 69.5° | 69.5° | 69.5° |
| F | Fork Rake (mm) (inch) | 44 | 44 | 44 | 44 |
| G | Trail (mm) (inch) | 87 | 87 | 87 | 87 |
| H | Wheelbase (mm) (inch) | 1120 | 1128 | 1138 | 1158 |
| I | Chain Stay Length (mm) (inch) | 470 | 470 | 470 | 470 |
| J | Bottom Bracket Drop (mm) (inch) | 50 | 50 | 50 | 50 |
| K | Stack (mm) (inch) | 625 | 625 | 662 | 662 |
| L | Reach (mm) (inch) | 391 | 399 | 395 | 415 |
| M | Stand Over Height (mm) (inch) | 592 | 564 | 524 | 488 |
| O | Stem Length (mm) (inch) | 90 | 90 | 110 | 110 |
| P | Crank Length (mm) (inch) | 170 | 170 | 170 | 170 |
| Q | Wheel Size | 27.5" | 27.5" | 27.5" | 27.5" |
| Motor | Giant SyncDrive Sport2, 75Nm, PedalPlus 6-sensor technology |
| Controller | Giant RideControl Ergo 2 remote, Smart Assist automatic mode, 5 support levels, USB-C (10W) |
| Display | Giant RideDash EVO, high-angle visibility, 3" full colour LCD display, on-board navigation |
| Battery | EnergyPak Smart 500Wh |
| Charger | Giant EnergyPak 4A smart charger compact, 60% charge in 2:30h |
| Connectivity | Giant RideControl App enabled ANT+ wireless display signal with e-bike profile |
| Sizes | S, M, L, XL |
| Colours | Snow Drift / Black |
| Frame | ALUXX SL aluminium, Integrated battery design, Headset integrated cable routing, KSA40 Kickstand |
| Fork | SR Suntour XCR32 ATB LO DS, 100mm travel, Hydraulic Lockout, 15x100mm |
| Shock | n/a |
| Handlebar | Giant Contour Comfort Riser 31.8mm |
| Grips | Giant Comfort Ergo Microtech Plus Lock-on |
| Stem | Giant Contour, RideDash EVO integrated, high adjustable, S:90mm, M:90mm, L:110mm, XL:110mm |
| Seatpost | Suspension dropper post, 30.9mm S: 60mm travel / 30.9 x 395mm M: 80mm travel / 30.9 x 405mm L: 100mm travel / 30.9 x 450mm XL: 100mm travel / 30.9 x 450mm |
| Saddle | Selle Royal Vivo Ergo Unisex |
| Pedals | Platform |
| Shifters | Shimano Deore 10-speed |
| Front Derailleur | n/a |
| Rear Derailleur | Shimano Deore, 10-speed, Shadow+ |
| Brakes | Tektro HD-M275, hydraulic disc, 180mm |
| Brake Levers | Tektro HD-M275 |
| Cassette | Shimano Deore, CS-M4100, 11-46T, 10-speed |
| Chain | KMC e.10 Sport, e-bike optimized |
| Crankset | Forged Alloy, 42T |
| Bottom Bracket | n/a |
| Rims | Giant eX25, Tubeless Ready, 584x25 Aluminium |
| Hubs | Shimano HB-MT200 100x9mm QR Disc [F] Shimano FH-QC400-HM [R] |
| Spokes | Stainless |
| Tires | Schwalbe Smart Sam Plus, 27.5x2.25", DD, GreenGuard, ADDIX, E-50 |
| Extras | KSA40 direct mount kickstand |
| Lighting | Giant Recon HL50, 50 lux [F] AXA Juno 6-12V E-bike tail light [R] |
| Lock | ABUS Xplus battery lock |
| Carrier | MIK rack. System bag & basket compatible |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
