The Avail Advanced Pro is the ultimate in lightweight efficiency, thanks to an all-new Advanced-grade composite frame and an Advanced SL-grade composite fork, which boosts your climbing abilities and makes you virtually uncatchable over long distances.
Ride longer without riding harder, with the reengineered frame and fork, optimised for the smoothest, most efficient riding experience. The innovative Liv Contact D-Fuse handlebar and D-Fuse seatpost absorb more road vibrations than round-shaped tubing, without sacrificing efficiency on corners and climbs.
The Liv Contact D-Fuse handlebar features an ergonomic shape and 8-degree flare drop, for total control on those all-day rides. Wide, hookless carbon rims are designed for high-volume tubeless tyres (up to 38mm) and a 36mm rim depth, providing predictable handling and stability from asphalt to pavé.
| XS | 153 cm - 162 cm |
| S | 158 cm - 169 cm |
| M | 165 cm - 174 cm |
| L | 171 cm - 182 cm |
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 405 | 435 | 465 | 495 |
| B | Seat Tube Angle (degrees) | 74.5° | 74.5° | 74.0° | 74.0° |
| C | Top Tube Length (mm) (inch) | 520 | 525 | 535 | 555 |
| D | Head Tube Length (mm) (inch) | 125 | 145 | 165 | 185 |
| E | Head Tube Angle (degrees) | 71.0° | 71.0° | 71.0° | 72.0° |
| F | Fork Rake (mm) (inch) | 50 | 50 | 50 | 50 |
| G | Trail (mm) (inch) | 68 | 68 | 68 | 61 |
| H | Wheelbase (mm) (inch) | 995 | 1002 | 1007 | 1013 |
| I | Chain Stay Length (mm) (inch) | 420 | 420 | 420 | 420 |
| J | Bottom Bracket Drop (mm) (inch) | 75 | 73 | 73 | 73 |
| K | Stack (mm) (inch) | 528 | 547 | 566 | 589 |
| K | StackToHandlebar (mm) (inch) | 606 | 626 | 647 | 668 |
| L | Reach (mm) (inch) | 373 | 373 | 373 | 381 |
| L | ReachToHandlebar (mm) (inch) | 420 | 429 | 439 | 449 |
| M | Stand Over Height (mm) (inch) | 712 | 737 | 762 | 789 |
| O | Stem Length (mm) (inch) | 70 | 80 | 90 | 90 |
| P | Crank Length (mm) (inch) | 165 | 170 | 170 | 172.5 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, L |
| Colours | Gloss Carbon/Matte Carbon/Chrome |
| Frame | Advanced-grade composite, 12x142mm thru-axle, disc |
| Fork | Advanced SL-grade composite, full-composite OverDrive Aero steerer, 12x100mm, disc |
| Shock | N/A |
| Handlebar | Giant Contact SLR D-Fuse, 31.8mm XS:38cm, S:40cm, M:40cm, L:42cm |
| Grips | Liv All Condition |
| Stem | Giant Contact SL Aerolight XS:70mm, S:80mm, M:90mm, L:90mm |
| Seatpost | Giant D-Fuse SLR, composite, -5/+15mm offset |
| Saddle | Liv Alacra SL |
| Pedals | N/A |
| Shifters | Shimano Ultegra Di2 ST-R8170 |
| Front Derailleur | Shimano Ultegra Di2 FD-R8150 |
| Rear Derailleur | Shimano Ultegra Di2 RD-R8150 |
| Brakes | Shimano Ultegra Di2 hydraulic, Shimano RT-CL800 rotors [F]160mm, [R]160mm |
| Brake Levers | Shimano Ultegra Di2 hydraulic |
| Cassette | Shimano Ultegra, 12-speed, 11x34 |
| Chain | KMC X12 |
| Crankset | Shimano Ultegra, 34/50 with Giant Power Pro power meter XS:165mm, S:170mm, M:170mm, L:172.5mm |
| Bottom Bracket | Shimano, press fit |
| Rims | Giant SLR 1 36 Carbon Disc WheelSystem, [F] 36mm, [R] 36mm |
| Hubs | [F] Giant Low Friction Hub, CenterLock, 12mm thru-axle [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | Sapim CX-Ray |
| Tires | Giant Gavia Fondo 0, tubeless, 700x32c (33.5mm), folding |
| Extras | Computer mount, water bottle cages, tubeless prepared, 38mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
