Free of cumbersome gimmickry, the frameset is one of the lightest in its category. With a perfect balance of high-performance reactivity and all-day comfort, it offers a “less is more” experience for modern endurance road riding.
Advanced SL-grade composite frame and fork are specifically engineered for endurance road riding, delivering a smooth and efficient ride quality that minimises fatigue on long rides. The new D-Fuse components work together to further absorb road shocks and vibrations.
A new Contact D-Fuse handlebar features ergonomic shaping and an 8-degree flare for comfort and control on all-day rides. Wide, hookless carbon rims (22.4mm inner width) are optimised for high-volume tubeless tyres (up to 38mm), and a 36mm rim depth offers stable, predictable handling in crosswinds.
| XS | 157 cm - 169 cm |
| S | 165 cm - 175 cm |
| M | 171 cm - 181 cm |
| ML | 177 cm - 187 cm |
| L | 183 cm - 193 cm |
| XL | 189 cm - 199 cm |
| XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 410 | 445 | 480 | 515 | 535 | 565 |
| B | Seat Tube Angle (degrees) | 74.5° | 74.0° | 73.5° | 73.0° | 73.0° | 73.0° |
| C | Top Tube Length (mm) (inch) | 515 | 530 | 545 | 560 | 575 | 595 |
| D | Head Tube Length (mm) (inch) | 120 | 140 | 150 | 175 | 195 | 215 |
| E | Head Tube Angle (degrees) | 70.5° | 71.8° | 72.5° | 72.5° | 72.5° | 72.5° |
| F | Fork Rake (mm) (inch) | 50 | 50 | 50 | 50 | 50 | 50 |
| G | Trail (mm) (inch) | 71.6 | 63.4 | 58.6 | 58.6 | 58.6 | 58.6 |
| H | Wheelbase (mm) (inch) | 995 | 994 | 998 | 1010 | 1025 | 1040 |
| I | Chain Stay Length (mm) (inch) | 420 | 420 | 420 | 420 | 420 | 420 |
| J | Bottom Bracket Drop (mm) (inch) | 75 | 75 | 75 | 70 | 70 | 70 |
| K | Stack (mm) (inch) | 527 | 541 | 558 | 577 | 596 | 615 |
| L | Reach (mm) (inch) | 369 | 375 | 380 | 384 | 393 | 402 |
| M | Stand Over Height (mm) (inch) | 705 | 733 | 762 | 796 | 814 | 841 |
| O | Stem Length (mm) (inch) | 80 | 90 | 100 | 100 | 110 | 110 |
| P | Crank Length (mm) (inch) | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Q | Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, M/L, L, XL |
| Colours | Blue Dragonfly/Black/Chrome |
| Frame | Advanced SL-grade composite, disc |
| Fork | Advanced SL-grade composite, full-composite OverDrive Aero steerer, disc |
| Shock | N/A |
| Handlebar | Giant Contact SLR D-Fuse XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm |
| Grips | Stratus Lite 3.0 |
| Stem | Giant Contact SLR AeroLight XS:80mm, S:90mm, M:100mm, M/L:100mm, L:110mm, XL:110mm |
| Seatpost | Giant SLR D-Fuse, composite, -5/+15mm offset |
| Saddle | Giant Fleet SLR |
| Pedals | N/A |
| Shifters | SRAM RED eTap AXS |
| Front Derailleur | SRAM RED eTap AXS |
| Rear Derailleur | SRAM RED eTap AXS |
| Brakes | SRAM RED eTap AXS hydraulic, SRAM CenterLine XR rotors [F]160mm, [R]160mm |
| Brake Levers | SRAM RED eTap AXS hydraulic |
| Cassette | SRAM Force, 12-speed, 10x36 |
| Chain | SRAM RED D1 |
| Crankset | SRAM RED D1 DUB, 33/46 with Quarq DZero power meter XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
| Bottom Bracket | SRAM DUB, press fit |
| Rims | CADEX 36 Disc WheelSystem, [F]36mm, [R]36mm |
| Hubs | [F] CADEX R1 Hub, CenterLock, 12mm thru-axle [R] CADEX R1-C30 Low Friction Hub, 40t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | CADEX Aero Carbon Spoke |
| Tires | CADEX Classic, tubeless, 700x32c (33.5mm), folding |
| Extras | Computer mount, fender mount, water bottle cages, tubeless prepared, 38mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
