Advanced Composite frameset and sleek shaping make this model 350g lighter than the aluminium version. A stiffer bottom bracket area improves power transfer so you can accelerate and climb faster with less effort.
Flat handlebar frame geometry creates a more upright riding position for confident handling. Powerful disc brakes offer added control in all conditions. And the combination of a D-Fuse composite seatpost and ErgoContact saddle helps smooth out rough roads.
High-volume 40mm tubeless tyres offer the freedom and versatility to ride smooth roads, bumpy bike paths or gravel. Single or double chainring setups are available on different models to suit individual riding style and terrain.
| XS | 155 cm - 165 cm |
| S | 160 cm - 170 cm |
| M | 170 cm - 180 cm |
| ML | 175 cm - 185 cm |
| L | 180 cm - 190 cm |
| XL | 190 cm - 200 cm |
| XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 435 | 455 | 475 | 495 | 525 | 555 |
| B | Seat Tube Angle (degrees) | 73.5° | 73.5° | 73.5° | 73.0° | 73.0° | 73.0° |
| C | Top Tube Length (mm) (inch) | 545 | 560 | 575 | 590 | 610 | 630 |
| D | Head Tube Length (mm) (inch) | 110 | 130 | 155 | 175 | 200 | 225 |
| E | Head Tube Angle (degrees) | 70.5° | 70.5° | 71.0° | 71.0° | 71.5° | 71.5° |
| F | Fork Rake (mm) (inch) | 50 | 50 | 50 | 50 | 50 | 50 |
| G | Trail (mm) (inch) | 73.7 | 73.7 | 70.4 | 70.4 | 67.1 | 67.1 |
| H | Wheelbase (mm) (inch) | 1031 | 1047 | 1058 | 1069 | 1084 | 1105 |
| I | Chain Stay Length (mm) (inch) | 435 | 435 | 435 | 435 | 435 | 435 |
| J | Bottom Bracket Drop (mm) (inch) | 75 | 75 | 75 | 75 | 75 | 75 |
| K | Stack (mm) (inch) | 533 | 552 | 578 | 597 | 623 | 646 |
| L | Reach (mm) (inch) | 387 | 396 | 404 | 407 | 419 | 432 |
| M | Stand Over Height (mm) (inch) | 718 | 736 | 756 | 773 | 800 | 826 |
| O | Stem Length (mm) (inch) | 70 | 80 | 90 | 90 | 100 | 110 |
| P | Crank Length (mm) (inch) | 170 | 170 | 170 | 172.5 | 172.5 | 172.5 |
| Q | Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, M/L, L, XL |
| Colours | Glacier Silver |
| Frame | Advanced-grade composite, disc |
| Fork | Advanced-grade composite, composite OverDrive steerer, disc |
| Shock | N/A |
| Handlebar | Giant Sport, mini-rise, 31.8mm |
| Grips | Giant ErgoContact |
| Stem | Giant Contact, 8-degree XS:70mm, S:80mm, M:90mm, M/L: 90mm, L:100mm, XL:110mm |
| Seatpost | Giant D-Fuse, composite |
| Saddle | Giant ErgoMax |
| Pedals | N/A |
| Shifters | Shimano Cues U6000 10 speed - SLU60010R |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano Cues U6000 10 speed |
| Brakes | Tektro HD-R280, Giant MPH rotors [F]160mm, [R]160mm |
| Brake Levers | Tektro HD-R280 |
| Cassette | Shimano CS-LG400 10, 11-48 |
| Chain | KMC Xglinde w/ Missing Link |
| Crankset | FSA Omega, 42 XS:170mm, S:170mm, M:170mm, M/L:172.5mm, L:172.5mm, XL: 172.5mm |
| Bottom Bracket | FSA, press fit |
| Rims | Giant SR-2 Wheel Set |
| Hubs | Giant alloy, 12mm thru-axle |
| Spokes | Sapim |
| Tires | Giant Gavia Fondo AR, tubeless, 700x40c |
| Extras | tubeless prepared, 42mm max tire size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
