The heart of the Langma is an ultra-light Advanced SL-Grade Composite frameset—which we’ve rebuilt with longer, more continuous pieces of carbon fibre for a stiffer bike that’s 60 grams lighter.* So you get a responsive ride that accelerates immediately, skims over rough roads and surges up climbs. And a translucent frame coating shows off this carbon construction, making the Langma look as fast as it feels. * Compared to the first-generation Langma Advanced SL frameset.
We’ve re-engineered the Langma fork for 50% more lateral stiffness,* for precise handling and responsiveness. An oversized headset and all-new Liv Contact SLR handlebar boost control without sacrificing aerodynamics. Integrated, flat-mount disc brakes deliver stopping confidence in varied conditions. The Langma even accommodates tyres up to 32mm for extra grip in the corners and cobbles. * Compared to the first-generation Langma Advanced SL fork.
Updated truncated ellipse tubing reduces wind drag at a wider range of yaw angles, gaining you precious seconds in flats, descents, and headwinds. Our relentless testing and refinement have also inspired the development of the new fully-carbon Variant SLR seatpost.
| XS | 152 cm - 163 cm |
| S | 158 cm - 169 cm |
| M | 164 cm - 176 cm |
| L | 170 cm - 183 cm |
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 420 | 450 | 480 | 510 |
| B | Seat Tube Angle (degrees) | 75.0° | 74.5° | 74.0° | 73.5° |
| C | Top Tube Length (mm) (inch) | 508 | 524 | 540 | 555 |
| D | Head Tube Length (mm) (inch) | 120 | 135 | 155 | 175 |
| E | Head Tube Angle (degrees) | 71.0° | 72.0° | 72.5° | 72.5° |
| F | Fork Rake (mm) (inch) | 49 | 49 | 49 | 49 |
| G | Trail (mm) (inch) | 67.8 | 61.4 | 58.2 | 58.2 |
| H | Wheelbase (mm) (inch) | 973 | 977 | 984 | 996 |
| I | Chain Stay Length (mm) (inch) | 405 | 405 | 405 | 405 |
| J | Bottom Bracket Drop (mm) (inch) | 72 | 70 | 70 | 67 |
| K | Stack (mm) (inch) | 517 | 532 | 553 | 569 |
| L | Reach (mm) (inch) | 370 | 377 | 382 | 386 |
| M | Stand Over Height (mm) (inch) | 700 | 730 | 760 | 790 |
| O | Stem Length (mm) (inch) | 80 | 90 | 100 | 110 |
| P | Crank Length (mm) (inch) | 165 | 170 | 170 | 172.5 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, L |
| Colours | Raw Carbon/Chrome |
| Frame | Advanced SL-grade composite, 12x142mm thru-axle, disc |
| Fork | Advanced SL-grade composite, full-composite OverDrive 2 steerer, 12x100mm, disc |
| Shock | N/A |
| Handlebar | Liv Contact SLR XS:36cm, S:38cm, M:40cm, L:42cm |
| Grips | Liv All Condition |
| Stem | Giant Contact SLR XS:80mm, S:90mm, M:100mm, L:110mm |
| Seatpost | Giant Variant SLR, composite, -5/+15mm offset |
| Saddle | Liv Alacra SLR |
| Pedals | N/A |
| Shifters | Shimano Dura-Ace Di2 ST-R9270 |
| Front Derailleur | Shimano Dura-Ace Di2 ST-R9250 |
| Rear Derailleur | Shimano Dura-Ace Di2 ST-R9250 |
| Brakes | Shimano Dura-Ace Di2 hydraulic, Shimano RT-MT900 rotors [F]160mm, [R]140mm |
| Brake Levers | Shimano Dura-Ace Di2 |
| Cassette | Shimano Dura-Ace, 12-speed, 11x34 |
| Chain | Shimano Dura-Ace M9100 |
| Crankset | Shimano Dura-Ace, 36/52 with Shimano FC-9200P power meter XS:165mm, S:170mm, M:170mm, L:172.5mm |
| Bottom Bracket | Shimano, press fit |
| Rims | CADEX 36 Disc WheelSystem, [F] 36mm, [R] 36mm |
| Hubs | [F] CADEX Low Friction Hub, CenterLock, 12mm thru-axle, [R] CADEX R1-C30 Hub, CenterLock, 12mm thru-axle |
| Spokes | CADEX Aero Carbon |
| Tires | CADEX Race, tubeless, 700x25c (28mm), folding |
| Extras | Computer mount, tubeless prepared, 32mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
