Flip chip feature lets you adjust the head tube and seat tube angles, as well as the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style.
Larger 29-inch diameter wheels optimised to roll over rough terrain with balance and stability, giving you the momentum to tackle technical climbs and the confidence to fly on fast, rugged singletrack descents.
Lightweight Advanced-grade composite frameset features a longer reach and steeper seat tube angle for aggressive trail riding and improved climbing capabilities. Maestro rear suspension features 120mm of travel paired with a 130mm fork up front.
| S | 163 cm - 172 cm |
| M | 171 cm - 180 cm |
| L | 179 cm - 188 cm |
| XL | 187 cm - 198 cm |
| Sizes | S, M, L, XL |
| Colours | Shoreline/Sea Sparkle/Chrome |
| Frame | Advanced-Grade Composite front and rear triangles, 120mm Maestro suspension, flip chip, UDH hanger, 12x148mm thru-axle, 55mm Chainline |
| Fork | Fox 34 Factory, 130mm, GRIP 2, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant |
| Shock | Fox Float X Factory, 2 position lever with LSC adjust, Trunnion, custom tuned for Giant |
| Handlebar | Giant Contact SLR Integrated, composite, 35mm |
| Grips | Giant Tactal Pro Single lock-on |
| Stem | Giant Contact SLR Trail, integrated, 40/45/50mm Reach, 7/9 degree Sweep Adjust System |
| Seatpost | Giant Contact Switch AT dropper, adjustable travel, remote |
| Saddle | Giant Romero SL |
| Pedals | N/A |
| Shifters | SRAM AXS Pod, 1x12 |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM XO Eagle T-Type AXS |
| Brakes | Shimano Deore XT BR-M8120, hydraulic, Shimano RT-66 rotors [F]180mm, [R]180mm |
| Brake Levers | Shimano Deore XT BL-M8100 |
| Cassette | SRAM XO, T-Type 10x52 |
| Chain | SRAM XO T-Type |
| Crankset | SRAM XO T-Type, 30t, 55mm chainline S:165mm, M:170mm, L:170mm, XL:170mm |
| Bottom Bracket | SRAM, press fit |
| Rims | Giant TRX 2 29 Carbon WheelSystem, 30mm inner width |
| Hubs | [F] Giant MTB alloy, 6-bolt [R] Giant MTB alloy, 3-pawl driver, 6-bolt |
| Spokes | Sapim |
| Tires | [F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Aggressor 29x2.5, EXO, TR, tubeless |
| Extras | Tubeless prepared, 2.6" max tyre size, 34t max chainring size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
