Frame is specifically engineered to produce a balanced, all-rounder feel that blends confident rider positioning with agile cornering and acceleration.
Innovative D-Fuse seatpost reduces road shocks and vibrations, and a Giant wheelset lets you run tubeless tyres up to 38mm for a smoother ride quality and reduced risk of flats.
Seamless disc brake integration, including flat mounts and 12mm front and rear thru-axles, produces more consistent braking power for better control, even in wet weather and on rough roads.
| XS | 157 cm - 169 cm |
| S | 165 cm - 175 cm |
| M | 171 cm - 181 cm |
| ML | 177 cm - 187 cm |
| L | 183 cm - 193 cm |
| XL | 189 cm - 199 cm |
| XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 430 | 465 | 500 | 535 | 555 | 585 |
| B | Seat Tube Angle (degrees) | 75.0° | 74.0° | 73.5° | 73.0° | 73.0° | 73.0° |
| C | Top Tube Length (mm) (inch) | 515 | 535 | 550 | 565 | 580 | 595 |
| D | Head Tube Length (mm) (inch) | 115 | 135 | 150 | 170 | 190 | 215 |
| E | Head Tube Angle (degrees) | 71.5° | 71.8° | 72.0° | 72.5° | 72.5° | 72.5° |
| F | Fork Rake (mm) (inch) | 53 | 53 | 53 | 53 | 53 | 53 |
| G | Trail (mm) (inch) | 62.9 | 61.3 | 59.6 | 56.4 | 56.4 | 56.4 |
| H | Wheelbase (mm) (inch) | 994 | 1003 | 1011 | 1015 | 1031 | 1046 |
| I | Chain Stay Length (mm) (inch) | 422 | 422 | 422 | 422 | 422 | 422 |
| J | Bottom Bracket Drop (mm) (inch) | 80 | 80 | 80 | 80 | 80 | 80 |
| K | Stack (mm) (inch) | 539 | 559 | 574 | 595 | 614 | 638 |
| L | Reach (mm) (inch) | 371 | 375 | 380 | 383 | 392 | 400 |
| M | Stand Over Height (mm) (inch) | 727 | 759 | 783 | 810 | 829 | 856 |
| O | Stem Length (mm) (inch) | 80 | 90 | 100 | 100 | 110 | 110 |
| P | Crank Length (mm) (inch) | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Q | Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, M/L, L, XL |
| Colours | Dark Iridescent |
| Frame | ALUXX-grade aluminium, 12x142mm thru-axle, disc |
| Fork | Advanced-grade composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Giant Connect XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm |
| Grips | Giant |
| Stem | Giant Sport XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:110mm |
| Seatpost | Giant D-Fuse, composite, 14mm offset |
| Saddle | Giant Approach |
| Pedals | N/A |
| Shifters | Shimano Tiagra |
| Front Derailleur | Shimano Tiagra |
| Rear Derailleur | Shimano Tiagra GS |
| Brakes | Shimano Tiagra, Giant MPH rotors [F]160mm, [R]160mm |
| Brake Levers | Shimano Tiagra hydraulic |
| Cassette | Shimano Tiagra, 11x34 |
| Chain | KMC X10-1 |
| Crankset | Shimano Tiagra, 34/50 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
| Bottom Bracket | Cartridge |
| Rims | Giant S-R2 Disc wheelset, alloy |
| Hubs | Giant alloy, 12mm thru-axle |
| Spokes | Sapim |
| Tires | Giant Gavia Fondo 2, tubeless, 700x32c (34mm) |
| Extras | Tubeless prepared, 38mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
