An ultralight Advanced-grade composite frame and fork make for snappy acceleration, while internal cable routing streamlines your cockpit and makes room for your must-have accessories. And the redesigned geometry puts you in a more aggressive position, increases traction and stability, and allows more control at speed and on descents.
The Contact XR D-Fuse handlebar features a 5-degree back sweep and flare drop for comfortable and ergonomic grip. Select models also feature the Contact D-Fuse seatpost and one is equipped with a dropper post. Or swap out for your preferred set-up. These proprietary D-Fuse components absorb bumps and reduce vibrations, ensuring less fatigue and more fun on those epic rides.
Adapt to the route with the flip chip – dropout, which lets you adjust your wheelbase length and rear-wheel tyre clearance. Go shorter for responsive handling and quick acceleration. Go longer for added stability plus clearance for larger tyres and extra traction. Plus, the integrated down tube storage lets you stash a multi-tool or extra fuel, so nothing’s slowing you down.
XS | 150 cm - 163 cm |
S | 158 cm - 169 cm |
M | 164 cm - 175 cm |
L | 170 cm - 181 cm |
Sizes | XS, S, M, L |
Colours | Ice Age |
Frame | Advanced-grade composite, 12x142mm thru-axle, flat mount disc, flip chip – dropout, integrated down tube storage |
Fork | Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc |
Shock | N/A |
Handlebar | Giant Contact XR D-Fuse, 31.8mm XS:40cm, S:40cm, M:42cm, L:42cm |
Grips | Liv All Condition |
Stem | Giant Contact AeroLight, -10-degree XS: 50mm, S: 60mm, M: 70mm, L: 80mm |
Seatpost | Postmodern, dropper, 30.9mm with 25mm of suspension XS:365mm / 75mm drop S:365mm / 75mm drop M:365mm / 75mm drop L:410mm / 100mm drop |
Saddle | Liv Approach |
Pedals | N/A |
Shifters | SRAM Apex 1, 1x12 |
Front Derailleur | N/A |
Rear Derailleur | SRAM Apex XPLR |
Brakes | SRAM Apex hydraulic, Giant MPH rotors [F]160mm, [R]160mm |
Brake Levers | SRAM Apex hydraulic, left lever dropper switch |
Cassette | SRAM PG-1231 D1 XPLR, 12-speed, 11x44 |
Chain | SRAM Apex D1 |
Crankset | SRAM Apex 1 Wide DUB, 40t XS: 165mm, S: 170mm, M: 172.5mm, L: 172.5mm |
Bottom Bracket | SRAM DUB, press fit |
Rims | Giant P-X2 Disc, alloy |
Hubs | Giant alloy, 12mm thru-axle |
Spokes | Sapim |
Tires | Giant Crosscut Grip, 700x45c, tubeless |
Extras | Tubeless prepared, 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position |
Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
