The re-engineered frameset and integrated components yield efficient power transfer for quick bursts of speed and sustained climbing prowess.
Up to 33mm tyre clearance means you’re ready for any road, from the freshly-poured to the weather-beaten, without compromising handling. The flared handlebar injects control and confidence into those explosive sprints and bomber descents.
With truncated ellipse tube shapes and a new internal cable routing design, you’ll reduce drag, pick up speed, and watch the scenery fly by.
| XS | 152 cm - 163 cm |
| S | 158 cm - 169 cm |
| M | 164 cm - 176 cm |
| L | 170 cm - 183 cm |
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 420 | 450 | 480 | 510 |
| B | Seat Tube Angle (degrees) | 75.0° | 74.5° | 74.0° | 73.5° |
| C | Top Tube Length (mm) (inch) | 508 | 524 | 540 | 555 |
| D | Head Tube Length (mm) (inch) | 120 | 135 | 155 | 175 |
| E | Head Tube Angle (degrees) | 71.0° | 72.0° | 72.5° | 72.5° |
| F | Fork Rake (mm) (inch) | 49 | 49 | 49 | 49 |
| G | Trail (mm) (inch) | 68 | 61 | 58 | 58 |
| H | Wheelbase (mm) (inch) | 973 | 977 | 984 | 994 |
| I | Chain Stay Length (mm) (inch) | 405 | 405 | 405 | 405 |
| J | Bottom Bracket Drop (mm) (inch) | 72 | 69.5 | 69.5 | 69.5 |
| K | Stack (mm) (inch) | 517 | 532 | 553 | 572 |
| L | Reach (mm) (inch) | 370 | 377 | 382 | 386 |
| M | Stand Over Height (mm) (inch) | 707 | 736 | 763 | 783 |
| O | Stem Length (mm) (inch) | 80 | 90 | 100 | 110 |
| P | Crank Length (mm) (inch) | 165 | 170 | 170 | 172.5 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, L |
| Colours | Aurora Noise |
| Frame | Advanced-Grade Composite, 12x142mm thru-axle, disc |
| Fork | Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc |
| Handlebar | Liv Contact SL XS:34/36cm, S:36/38cm, M:38/40cm, L:39/42cm |
| Grips | Liv Stratus Elite 2.0 |
| Stem | Giant Contact SL AeroLight XS:80mm, S:90mm, M:100mm, L:110mm |
| Seatpost | Giant Variant, composite, -5/+15mm offset |
| Saddle | Liv Alacra SL |
| Shifters | Shimano 105 Di2 |
| Front Derailleur | Shimano 105 Di2 FD-R7150 |
| Rear Derailleur | Shimano 105 Di2 RD-R7150 |
| Brakes | Shimano 105 Di2 hydraulic, Shimano SM-RT70 rotors [F] 160mm, [R] 140mm |
| Brake Levers | Shimano 105 Di2 |
| Cassette | Shimano 105, 12-speed, 11x34 |
| Chain | KMC X12 |
| Crankset | Shimano 105, 36/52 with Giant Power Pro power meter XS:165mm, S:170mm, M:170mm, L:172.5mm |
| Bottom Bracket | Shimano, press fit |
| Rims | Giant SLR 1 40 WheelSystem, [F] 40mm, [R] 40mm |
| Hubs | [F] Giant Low Friction Hub, CenterLock, 12mm thru-axle [R] Giant Low Friction Hub, 40t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | Sapim CX-Ray |
| Tires | Giant Gavia Course 0, tubeless, 700x25c (28mm), folding |
| Extras | Computer mount, tubeless prepared, 33mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
