The new frameset includes an all-new Variant Integrated Seatpost, which means less weight, greater compliance, and improved aero performance—turning every pedal stroke into a burst of “let’s go.”
The flared handlebar injects control and confidence into those explosive sprints and bomber descents. Ready to race the cobbles? Run up to 33mm tyres, without sacrificing precise handling.
With a truncated ellipse tube shape, the new frameset is built to slice through wind and pelotons. A new internal cable routing design delivers a streamlined cockpit and added aero advantage.
| XS | 152 cm - 163 cm |
| S | 158 cm - 169 cm |
| M | 164 cm - 176 cm |
| L | 170 cm - 183 cm |
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 640 | 680 | 720 | 760 |
| B | Seat Tube Angle (degrees) | 75.0° | 74.5° | 74.0° | 73.5° |
| C | Top Tube Length (mm) (inch) | 508 | 524 | 540 | 555 |
| D | Head Tube Length (mm) (inch) | 120 | 135 | 155 | 175 |
| E | Head Tube Angle (degrees) | 71.0° | 72.0° | 72.5° | 72.5° |
| F | Fork Rake (mm) (inch) | 49 | 49 | 49 | 49 |
| G | Trail (mm) (inch) | 68 | 61 | 58 | 58 |
| H | Wheelbase (mm) (inch) | 973 | 977 | 984 | 994 |
| I | Chain Stay Length (mm) (inch) | 405 | 405 | 405 | 405 |
| J | Bottom Bracket Drop (mm) (inch) | 72 | 69.5 | 69.5 | 69.5 |
| K | Stack (mm) (inch) | 517 | 532 | 553 | 572 |
| L | Reach (mm) (inch) | 370 | 377 | 382 | 386 |
| M | Stand Over Height (mm) (inch) | 707 | 736 | 763 | 783 |
| O | Stem Length (mm) (inch) | 80 | 90 | 100 | 110 |
| P | Crank Length (mm) (inch) | 165 | 170 | 170 | 172.5 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, L |
| Colours | Tahitian Pearl/Chrome |
| Frame | Advanced SL-Grade Composite, 12x142mm thru-axle, integrated seatpost, disc |
| Fork | Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc |
| Handlebar | Liv Contact SLR XS:34/36cm, S:36/38cm, M:38/40cm, L:39/42cm |
| Grips | Liv Stratus Elite 2.0 |
| Stem | Giant Contact SLR AeroLight XS:80mm, S:90mm, M:100mm, L:110mm |
| Seatpost | Liv Integrated Seatpost, -5/+15mm offset |
| Saddle | CADEX AMP |
| Shifters | SRAM RED AXS |
| Front Derailleur | SRAM RED AXS |
| Rear Derailleur | SRAM RED AXS |
| Brakes | SRAM RED eTap hydraulic, SRAM PaceLine X rotors [F] 160mm, [R] 140mm |
| Brake Levers | SRAM RED AXS |
| Cassette | SRAM RED, 12-speed, 10x33 |
| Chain | SRAM RED |
| Crankset | SRAM RED AXS, 35/48 with power meter XS:165mm, S:170mm, M:170mm, L:172.5mm |
| Bottom Bracket | SRAM DUB |
| Rims | CADEX Max 40 WheelSystem, [F] 40mm, [R] 40mm |
| Hubs | [F] CADEX R3 Hub, CenterLock, 12mm thru-axle [R] CADEX R3-C48 Aero Hub, 48t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | CADEX Aero Carbon Spoke |
| Tires | CADEX Race GC, tubeless, 700x28c (28mm), folding |
| Extras | Computer mount, tubeless prepared, 33mm max tyre size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
