AeroSystem Shaping, a result of CFD analysis and dynamic wind-tunnel testing, optimizes aerodynamic performance at every yaw angle. The truncated ellipse airfoil tube shapes and Contact SLR Aero cockpit produce the best overall aero performance.
Cable routing through the stem and head tube makes it quicker and easier to adjust or change cockpit components and fine-tune performance and riding position.
Advanced SL-grade composite frameset features Giant’s pro-level composite materials and manufacturing processes. The result is 225 grams of weight savings compared to the previous generation and an even greater stiffness-to-weight advantage.
| XS | 157 cm - 169 cm |
| S | 165 cm - 175 cm |
| M | 171 cm - 181 cm |
| ML | 177 cm - 187 cm |
| L | 183 cm - 193 cm |
| XL | 189 cm - 199 cm |
| XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 680 | 710 | 740 | 770 | 800 | 830 |
| B | Seat Tube Angle (degrees) | 74.5° | 74.0° | 73.5° | 73.0° | 73.0° | 72.5° |
| C | Top Tube Length (mm) (inch) | 520 | 535 | 550 | 565 | 580 | 600 |
| D | Head Tube Length (mm) (inch) | 120 | 130 | 145 | 165 | 185 | 200 |
| E | Head Tube Angle (degrees) | 71.0° | 72.3° | 73.0° | 73.0° | 73.0° | 73.0° |
| F | Fork Rake (mm) (inch) | 45 | 45 | 45 | 45 | 45 | 45 |
| G | Trail (mm) (inch) | 70.5 | 62.5 | 57.8 | 57.8 | 57.8 | 57.8 |
| H | Wheelbase (mm) (inch) | 976 | 977 | 980 | 991 | 1006 | 1020 |
| I | Chain Stay Length (mm) (inch) | 405 | 405 | 405 | 405 | 405 | 405 |
| J | Bottom Bracket Drop (mm) (inch) | 72 | 70 | 70 | 67 | 67 | 67 |
| K | Stack (mm) (inch) | 517 | 528 | 545 | 562 | 581 | 596 |
| L | Reach (mm) (inch) | 376 | 383 | 388 | 393 | 402 | 412 |
| M | Stand Over Height (mm) (inch) | 734 | 755 | 775 | 794 | 821 | 834 |
| O | Stem Length (mm) (inch) | 80 | 90 | 100 | 110 | 110 | 120 |
| P | Crank Length (mm) (inch) | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Q | Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, M/L, L, XL |
| Colours | Black Lava/Monogram |
| Frame | Advanced SL-Grade Composite, 12x142mm thru-axle, integrated seatpost, disc |
| Fork | Advanced SL-grade composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Giant Contact SLR Aero XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm |
| Grips | Stratus Lite 2.0 |
| Stem | Giant Contact SLR Aero XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm |
| Seatpost | Advanced SL-grade composite, integrated design, -5/+15mm offset |
| Saddle | CADEX AMP |
| Pedals | N/A |
| Shifters | Shimano Dura-Ace Di2 ST-R9270 |
| Front Derailleur | Shimano Dura-Ace Di2 ST-R9250 |
| Rear Derailleur | Shimano Dura-Ace Di2 ST-R9250 |
| Brakes | Shimano Dura-Ace Di2 hydraulic, Shimano RT-CL900 rotors [F]160mm, [R]140mm |
| Brake Levers | Shimano Dura-Ace Di2 |
| Cassette | Shimano Dura-Ace, 12-speed, 11x30 |
| Chain | Shimano Dura-Ace M9100 |
| Crankset | Shimano Dura-Ace FC-R9200, 36/52 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
| Bottom Bracket | Shimano, press fit |
| Rims | CADEX 50 Ultra Disc WheelSystem, [F]50mm, [R]50mm |
| Hubs | [F] CADEX R3 Aero Hub, CenterLock, 12mm thru-axle, [R] CADEX R3-C40 Aero Low Friction Hub, 40T ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | CADEX Super Aero Carbon Spoke |
| Tires | CADEX Aero, tubeless, 700x25c (26.5mm), folding |
| Extras | Computer mount, water bottle cages, tubeless prepared, 30mm max tyre size |
| Max Tire Clearance | 32mm |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
